Festflanschverbindungen verzinkt, für Einklemmklappen
FLV WAEK WAFER
PDF-Version
Download
Zum Warenkorb hinzufügen
Diese Seite teilen
|
Artikel-Nr. |
DN |
PN |
E |
∅ K |
e |
Gewindebohrung |
Gewindesackloch |
||
|
M x L |
Stück |
M x L1 |
Stück |
||||||
|
FLV WAEK40V |
40 |
10/16 |
33 |
110 |
19.0 |
M16 x 100 |
4 |
- |
- |
|
FLV WAEK50V |
50 |
10/16 |
43 |
125 |
19.0 |
M16 x 100 |
4 |
- |
- |
|
FLV WAEK65V |
65 |
10/16 |
46 |
145 |
19.0 |
M16 x 120 |
4 |
- |
- |
|
FLV WAEK80V |
80 |
10/16 |
46 |
160 |
19.0 |
M16 x 120 |
8 |
- |
- |
|
FLV WAEK100V |
100 |
10/16 |
52 |
180 |
19.0 |
M16 x 120 |
8 |
- |
- |
|
FLV WAEK125V |
125 |
10/16 |
56 |
210 |
19.0 |
M16 x 120 |
8 |
- |
- |
|
FLV WAEK150V |
150 |
10/16 |
56 |
240 |
19.0 |
M20 x 130 |
8 |
- |
- |
|
FLV WAEK200V10 |
200 |
10 |
60 |
295 |
20.0 |
M20 x 130 |
8 |
- |
- |
|
FLV WAEK200V16 |
200 |
16 |
60 |
295 |
20.0 |
M20 x 130 |
12 |
- |
- |
|
FLV WAEK250V10 |
250 |
10 |
68 |
350 |
22.0 |
M20 x 160 |
12 |
- |
- |
|
FLV WAEK250V16 |
250 |
16 |
68 |
355 |
22.0 |
M24 x 150 |
12 |
- |
- |
|
FLV WAEK300V10 |
300 |
10 |
78 |
400 |
24.5 |
M20 x 160 |
12 |
- |
- |
|
FLV WAEK300V16 |
300 |
16 |
78 |
410 |
24.5 |
M24 x 160 |
12 |
- |
- |
|
FLV WAEK350V10 |
350 |
10 |
78 |
460 |
24.5 |
M20 x 160 |
16 |
- |
- |
|
FLV WAEK350V16 |
350 |
16 |
78 |
470 |
26.5 |
M24 x 180 |
16 |
- |
- |
|
FLV WAEK400V10 |
400 |
10 |
102 |
515 |
24.5 |
M24 x 180 |
16 |
- |
- |
|
FLV WAEK400V16 |
400 |
16 |
102 |
525 |
28.0 |
M27 x 200 |
16 |
- |
- |
|
FLV WAEK500V10 |
500 |
10 |
127 |
620 |
26.5 |
M24 x 220 |
20 |
- |
- |
|
FLV WAEK500V16 |
500 |
16 |
127 |
650 |
31.5 |
M30 x 230 |
20 |
- |
- |
|
FLV WAEK600V10 |
600 |
10 |
154 |
725 |
30.0 |
M27 x 250 |
20 |
- |
- |
|
FLV WAEK600V16 |
600 |
16 |
154 |
770 |
36.0 |
M33 x 280 |
20 |
- |
- |
|
FLV WAEK700V10 |
700 |
10 |
165 |
840 |
32.5 |
M27 x 270 |
20 |
M27 x 80 |
8 |
|
FLV WAEK700V16 |
700 |
16 |
165 |
840 |
39.5 |
M33 x 280 |
20 |
M33 x 85 |
8 |
|
FLV WAEK800V10 |
800 |
10 |
190 |
950 |
35.0 |
M30 x 310 |
20 |
M30 x 110 |
8 |
|
FLV WAEK800V16 |
800 |
16 |
190 |
950 |
43.0 |
M36 x 340 |
20 |
M36 x 80 |
8 |
|
FLV WAEK900V10 |
900 |
10 |
203 |
1050 |
37.5 |
M30 x 310 |
24 |
M30 x 100 |
8 |
|
FLV WAEK900V16 |
900 |
16 |
203 |
1050 |
48.5 |
M36 x 340 |
24 |
M36 x 100 |
8 |
|
FLV WAEK1000V10 |
1000 |
10 |
216 |
1160 |
40.0 |
M33 x 340 |
24 |
M33 x 95 |
8 |
|
FLV WAEK1000V16 |
1000 |
16 |
216 |
1170 |
50.0 |
M39 x 370 |
24 |
M39 x 100 |
8 |
|
FLV WAEK1100V10 |
1100 |
10 |
216 |
1270 |
42.5 |
M33 x 340 |
28 |
M33 x 100 |
8 |
|
FLV WAEK1100V16 |
1100 |
16 |
216 |
1270 |
53.5 |
M39 x 370 |
28 |
M39 x 110 |
8 |
|
FLV WAEK1200V10 |
1200 |
10 |
254 |
1380 |
45.0 |
M36 x 400 |
28 |
M36 x 110 |
8 |
|
FLV WAEK1200V16 |
1200 |
16 |
254 |
1390 |
57.0 |
M45 x 420 |
28 |
M45 x 115 |
8 |
Alle Masse in mm - Änderungen vorbehalten
