Wasser
Flansch- Spitzend-Stück
Typ F
PDF-Version
Download
Zum Warenkorb hinzufügen
Diese Seite teilen
|
Artikel-Nr. |
DN |
PN |
d |
L |
L’ |
e |
kg |
NPK-Nr. | DS (2D) | SA (2D) | VA (2D) | 3D | |||
|
F80E |
80 |
10/16 |
98 |
350 |
215 |
7.0 |
8.5 |
237.211 |
|
|
|
||||
|
F100E |
100 |
10/16 |
118 |
360 |
215 |
7.2 |
10.5 |
237.212 |
|
|
|
||||
|
F125E |
125 |
10/16 |
144 |
370 |
220 |
7.5 |
14.0 |
237.213 |
|
|
|
||||
|
F150E |
150 |
10/16 |
170 |
380 |
225 |
7.8 |
17.5 |
237.214 |
|
|
|
||||
|
F200 10E |
200 |
10 |
222 |
400 |
230 |
8.4 |
25.5 |
237.235 |
|
|
|
||||
|
F200 16E |
200 |
16 |
222 |
400 |
230 |
8.4 |
25.5 |
237.255 |
|
|
|
||||
|
F250 10E |
250 |
10 |
274 |
420 |
240 |
9.0 |
39.5 |
237.236 |
|
|
|
||||
|
F250 16E |
250 |
16 |
274 |
420 |
240 |
9.0 |
39.5 |
237.256 |
|
|
|
||||
|
F300 10E |
300 |
10 |
326 |
440 |
250 |
9.6 |
47.6 |
237.237 |
|
|
|
||||
|
F300 16E |
300 |
16 |
326 |
440 |
250 |
9.6 |
47.6 |
237.257 |
|
|
|
||||
|
F350 10E |
350 |
10 |
378 |
460 |
260 |
10.2 |
62.1 |
- |
|||||||
|
F350 16E |
350 |
16 |
378 |
460 |
260 |
10.2 |
65.9 |
- |
|||||||
|
F400 10E |
400 |
10 |
429 |
480 |
270 |
10.8 |
80.5 |
237.238 |
|
|
|
||||
|
F400 16E |
400 |
16 |
429 |
480 |
270 |
10.8 |
88.6 |
237.258 |
|
|
|
||||
|
F500 10E |
500 |
10 |
532 |
520 |
290 |
12.0 |
121.0 |
- |
|
|
|
||||
|
F500 16E |
500 |
16 |
532 |
520 |
290 |
12.0 |
140.4 |
- |
|
|
|
||||
|
F600 10E |
600 |
10 |
635 |
560 |
310 |
13.2 |
193.3 |
- |
|
|
|
||||
|
F600 16E |
600 |
16 |
635 |
560 |
310 |
13.2 |
208.9 |
- |
|
|
|
||||
|
F700 10E |
700 |
10 |
738 |
600 |
330 |
14.4 |
229.5 |
- |
|||||||
|
F700 16E |
700 |
16 |
738 |
600 |
330 |
14.4 |
227.0 |
- |
|
|
|
||||
|
F800 10E |
800 |
10 |
842 |
600 |
330 |
15.6 |
314.3 |
- |
|||||||
|
F800 16E |
800 |
16 |
842 |
600 |
330 |
15.6 |
320.0 |
- |
Alle Masse in mm - Änderungen vorbehalten
