Wasser
Bogen 90° mit Fuss 2 Flanschen
Typ N
PDF-Version
Download
Zum Warenkorb hinzufügen
Diese Seite teilen
|
Artikel-Nr. |
DN |
PN |
L |
c |
d |
e |
kg |
NPK-Nr. | DS (2D) | SA (2D) | VA (2D) | |||
|
N80E |
80 |
10/16 |
165 |
110 |
170 |
7.0 |
15.7 |
242.711 |
|
|||||
|
N100E |
100 |
10/16 |
180 |
125 |
200 |
7.2 |
18.9 |
242.712 |
|
|||||
|
N125E |
125 |
10/16 |
200 |
140 |
225 |
7.5 |
27.0 |
242.713 |
|
|||||
|
N150E |
150 |
10/16 |
220 |
160 |
250 |
7.8 |
34.6 |
242.714 |
|
|||||
|
N200 10E |
200 |
10 |
260 |
190 |
300 |
8.4 |
55.6 |
242.725 |
|
|||||
|
N200 16E |
200 |
16 |
260 |
190 |
300 |
8.4 |
55.6 |
242.735 |
|
|||||
|
N250 10E |
250 |
10 |
350 |
225 |
350 |
9.0 |
84.0 |
242.726 |
|
|||||
|
N250 16E |
250 |
16 |
350 |
225 |
350 |
9.0 |
84.0 |
242.736 |
|
|||||
|
N300 10E |
300 |
10 |
400 |
255 |
400 |
9.6 |
117.7 |
242.727 |
|
|||||
|
N300 16E |
300 |
16 |
400 |
255 |
400 |
9.6 |
117.7 |
242.737 |
|
|||||
|
N350 10E |
350 |
10 |
450 |
290 |
450 |
10.2 |
137.0 |
- |
||||||
|
N350 16E |
350 |
16 |
450 |
290 |
450 |
10.2 |
142.0 |
- |
||||||
|
N400 10E |
400 |
10 |
500 |
320 |
500 |
10.8 |
263.5 |
- |
||||||
|
N400 16E |
400 |
16 |
500 |
320 |
500 |
10.8 |
248.0 |
- |
||||||
|
N500 10E |
500 |
10 |
600 |
385 |
600 |
12.0 |
374.8 |
- |
||||||
|
N500 16E |
500 |
16 |
600 |
385 |
600 |
12.0 |
311.0 |
- |
||||||
|
N600 10E |
600 |
10 |
700 |
450 |
700 |
13.2 |
538.9 |
- |
||||||
|
N600 16E |
600 |
16 |
700 |
450 |
700 |
13.2 |
482.0 |
- |
||||||
|
N700 10E |
700 |
10 |
800 |
480 |
800 |
16.0 |
752.0 |
- |
||||||
|
N700 16E |
700 |
16 |
800 |
480 |
800 |
16.0 |
705.0 |
- |
||||||
|
N800 10E |
800 |
10 |
900 |
540 |
900 |
19.0 |
926.0 |
- |
||||||
|
N800 16E |
800 |
16 |
900 |
540 |
900 |
19.0 |
970.0 |
- |
Alle Masse in mm - Änderungen vorbehalten
