Wasser
Rohr, 1 Flansch
Typ F (L=100–2000 mm)
PDF-Version
Download
Zum Warenkorb hinzufügen
Diese Seite teilen
|
Artikel-Nr. |
DN |
PN |
d |
max. L |
e |
kg/m ohne Flansch |
kg Flansch |
NPK-Nr. | |
|
F40L1000E |
40 |
10/16 |
56 |
1000 |
7.0 |
6.9 |
1.7 |
- |
|
|
F50L1000E |
50 |
10/16 |
66 |
1000 |
7.0 |
10.7 |
2.1 |
- |
|
|
F65L1000E |
65 |
10/16 |
82 |
1000 |
7.0 |
11.0 |
2.6 |
- |
|
|
F80L2000E |
80 |
10/16 |
98 |
2000 |
7.0 |
16.1 |
2.8 |
241.431 |
|
|
F100L2000E |
100 |
10/16 |
118 |
2000 |
7.2 |
20.4 |
3.3 |
241.432 |
|
|
F125L2000E |
125 |
10/16 |
144 |
2000 |
7.5 |
26.4 |
4.0 |
241.443 |
|
|
F150L2000E |
150 |
10/16 |
170 |
2000 |
7.8 |
32.4 |
5.0 |
241.434 |
|
|
F200L2000 10E |
200 |
10 |
222 |
2000 |
8.4 |
46.1 |
6.9 |
241.535 |
|
|
F200L2000 16E |
200 |
16 |
222 |
2000 |
8.4 |
46.1 |
6.7 |
241.635 |
|
|
F250L2000 10E |
250 |
10 |
274 |
2000 |
9.0 |
61.3 |
9.8 |
241.536 |
|
|
F250L2000 16E |
250 |
16 |
274 |
2000 |
9.0 |
61.3 |
9.4 |
241.626 |
|
|
F300L2000 10E |
300 |
10 |
326 |
2000 |
9.6 |
78.1 |
13.0 |
241.547 |
|
|
F300L2000 16E |
300 |
16 |
326 |
2000 |
9.6 |
78.1 |
12.6 |
241.637 |
|
|
F350L2000 10E |
350 |
10 |
378 |
2000 |
10.2 |
96.5 |
14.7 |
- |
|
|
F350L2000 16E |
350 |
16 |
378 |
2000 |
10.2 |
96.5 |
17.5 |
- |
|
|
F400L2000 10E |
400 |
10 |
429 |
2000 |
10.8 |
116.2 |
17.2 |
241.538 |
|
|
F400L2000 16E |
400 |
16 |
429 |
2000 |
10.8 |
116.2 |
22.1 |
241.638 |
|
|
F500L2000 10E |
500 |
10 |
532 |
2000 |
12.0 |
160.6 |
23.2 |
- |
|
|
F500L2000 16E |
500 |
16 |
532 |
2000 |
12.0 |
160.6 |
37.4 |
- |
|
|
F600L2000 10E |
600 |
10 |
635 |
2000 |
13.2 |
211.3 |
32.8 |
- |
|
|
F600L2000 16E |
600 |
16 |
635 |
2000 |
13.2 |
211.3 |
57.6 |
- |
|
|
F700L2000 10E |
700 |
10 |
738 |
2000 |
14.4 |
268.5 |
44.3 |
- |
|
|
F700L2000 16E |
700 |
16 |
738 |
2000 |
14.4 |
268.5 |
57.4 |
- |
|
|
F800L2000 10E |
800 |
10 |
842 |
2000 |
5.6 |
332.1 |
58.5 |
- |
|
|
F800L2000 16E |
800 |
16 |
842 |
2000 |
15.6 |
332.1 |
76.8 |
- |
|
|
F900L2000 10E |
900 |
10 |
945 |
2000 |
16.8 |
401.7 |
69.6 |
- |
|
|
F900L2000 16E |
900 |
16 |
945 |
2000 |
16.8 |
401.7 |
91.4 |
- |
|
|
F1000L2000 10E |
1000 |
10 |
1048 |
2000 |
18.0 |
477.7 |
87.6 |
- |
|
|
F1000L2000 16E |
1000 |
16 |
1048 |
2000 |
18.0 |
477.7 |
127.0 |
- |
|
|
F1200L1000 10E |
1200 |
10 |
1255 |
1000 |
20.4 |
565.2 |
121.0 |
- |
|
|
F1200L1000 16E |
1200 |
16 |
1255 |
1000 |
20.4 |
565.2 |
185.0 |
- |
Alle Masse in mm - Änderungen vorbehalten
